General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Wall Mounted |
| Ventilation Type | Ducted |
| Ventilation Direction | Vertical |
| Vent Location | Top |
| Grease Filter Type | Baffle |
| Duct Size (in.) | 10 |
| Bulb Type | LED |
| Maximum CFM | 1200 |
| Range Hood Features | Dishwasher Safe Filter, Light |
| Fan Speed Options | 3 |
| Outdoor Approved | Yes |
| Appliance Fit Width (in.) | 48 |
| Width (in.) | 48 |
| Height (in.) | 24 |
| Depth (in.) | 32 |
| Product Weight (lbs.) | 157 |
| Collection | 7200 Series |
| Series | 7200 Series |
| Voltage | 120 |
| Amp | 15/20 |
| Frequency | 60 |
Specifications |
| Models | 36”, 42”, 48”, 54”, 60”, 66” & 72” |
| CFM | Two or four internal sealed motors deliver 1200 CFM or 2300 CFM Optional in-line blowers deliver 1266 CFM |
| Material | Heavy gauge commercial stainless steel (#304 grade, 22-gauge) Dimmable 50 watt halogen lights |
| Filters | Four 12” by 14” baffle filters improve performance (six or eight filters on larger models) Design of the stainless steel commercial baffle filters adds a professional appearance and improved performance |
| Installation | Generously proportioned 32” depth at bottom, 15″ depth at top, 24″ high hood provides an exceptional capture area |
Height Options |
| Range Hoods (36", 42", 48", 54", 60", 66", 72") Duct Covers: MODEL #: DC7201S, DC7201D | 12" or 13"-24" *Sold separately for ceilings 9' to 10' |
| Rear Option Conversion (36", 42", 48", 54", 60", 66", 72") Duct Covers: MODEL #: DC7200S, DC7200D | 24" or 25"-48" *Sold separately for ceilings 10' to 12' |
