Zephyr Monsoon Mini 34.38" Stainless Steel Custom Hood Liner

Zephyr

Model #:

AK9134AS-BF-CL

Model #: AK9134AS-BF-CL
1584554
Zephyr
$399.00

At a Glance

Good things come in small packages, and in this case it’s the Monsoon Mini one-piece liner. Includes dual-level halogen lights, 3-speed mechanical slide controls and the newly upgraded hybrid baffle filters. Equipped with a 300 CFM blower and the ability to duct either vertically or horizontally.Read More

Available in Store Only
Sale $399.00

$519.00

Save $120.00

Get to know this product.

Product Overview

Product Overview

Good things come in small packages, and in this case it’s the Monsoon Mini one-piece liner. Includes dual-level halogen lights, 3-speed mechanical slide controls and the newly upgraded hybrid baffle filters. Equipped with a 300 CFM blower and the ability to duct either vertically or horizontally.

Dual-Level Lighting

Halogen Lighting

Aluminum Mesh Filters

Mechanical Slide Controls

Optional Recirculating Kit

Vertical or Horizontal Ducting

Useful Documents
Manual
Spec Sheet
Specifications

General Specs

Height (in.)6.13
Depth (in.)18.06
ColorStainless Steel
Manufacturer Warranty1 Year Labor / 3 Year Parts
Color Finish NameStainless Steel
Range Hood TypeInsert
ENERGY STAR CertifiedNo
Maximum CFM300
Voltage120
Amp1.5
Frequency60

Overview

Size34-3/8” (36”)
Blower CFM (Min. - Max.)150 - 300
Sones (Min. - Max.)1.5 - 4
ControlsMechanical Slide
Speed Levels3
Lighting35W x 2
Dual-Level LightingYes
FiltersHybrid Baffle x 2
Recirculating OptionYes
Mounting Height Range26” - 36”

Duct Specifications

Vertical Internal Blower7” Round, 3-1/4” x 10”
Horizontal Internal Blower3-1/4” x 10”
